Frequency Inverter Avocado Oil Decanter Centrifuge AVOT-2 Model for EVOO Extraction
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | HENAN SOLID |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $28,000.00 - $30,000.00/sets |
| Packaging Details: | All core equipment and spare parts are packed by exported standard wooden cases. |
| Supply Ability: | 30 Set/Sets per Year |
|
Detail Information |
|||
| Type: | Extraction Equipment | Product Type: | Avocado Oil |
|---|---|---|---|
| Condition: | New | Video Outgoing-inspection: | Provided |
| Machinery Test Report: | Provided | Marketing Type: | Avocado Oil |
| Warranty Of Core Components: | 2 Years | Core Components: | Engine, Bearing |
| Voltage: | 220V/380V/415V/440V | Power: | 15KW |
| Weight: | 1200 | Dimension(L*W*H): | 2700X800X900MM |
| Warranty: | 2 Years | Key Selling Points: | Long Service Life |
| Applicable Industries: | Food & Beverage Factory, Farms | Showroom Location: | Italy, Peru, Mexico, Kenya |
| Product Name: | Avocado Oil Decanter Centrifuge | Model: | AVOT-2 |
| Capacity: | 500KG/H | Separation Method: | 2-phase |
| Rotation Speed: | Max.4500rpm | Speed Control: | Frequency Inverter |
| Differential: | 2rpm-31rpm | Main Motor+Vice Motor: | 15KW (ABB/SIEMENS) |
| Power Supply: | 220V/380V/415V/440V | Dimensions&Weight: | 2700X800X900MM/1200KGS |
| Port: | QINGDAO,SHANGHAI | ||
Product Description
AVOT Series Decanter Centrifuge
(Special Design for Avocado Oil Production)
AVOT series decanter centrifuge is designed specially for avocado oil extraction from the ready paste by 2-phase or 3-phase separation.Together with our polishing separator,customer can produce the extra virgin avocado oil.
It can run continuously 24 hours a day. This centrifuge is mainly composed of driving device,differential,screw,drum,frame, machine base and control system.
AVOT Two Phase Decanter Centrifuge
AVOT Series 2 phase decanter centrifuge is designed for avocado oil extraction to avoid waste water discharge pollution
AVOT Three Phase Decanter Centrifuge
AVOT Series 3 phase decanter centrifuge is designed for avocado oil extraction to get more drier avocado paste
Specification
MODEL | AVOT-2 | AVOT-3 | AVOT-4 | AVOT-5 | AVOT-6 | |||
CAPACITY | 500KG/H | 2000KG/H | 4000KG/H | 6000kg/h | 10000kg/h | |||
SEPARATION | 2-PHASE | 2/3-PHASE | 2/3-PHASE | 2/3-PHASE | 2/3-PHASE | |||
SPEED | 4500RPM | 3600RPM | 3300RPM | 3000RPM | 2800RPM | |||
MATERIAL | SUS304 | 304/316/2205/2507 (DIN 1.4301/1.4401/1.4462/1.4410) | ||||||
DIMENSION | 2700*800*900MM | 3500*1000*1250MM | 4200*1200*1300MM | 4600*1500*1600MM | 4800*1800*1900MM | |||
Packing & Delivery
