Long Service Life EVOT-5 5T/H Extra Virgin Olive Oil Tricanter for 3 Phase Separation
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | HENAN SOLID |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $95,000.00 - $110,000.00/sets |
| Packaging Details: | All core equipment and spare parts are packed by exported standard wooden cases. |
| Supply Ability: | 30 Set/Sets per Year |
|
Detail Information |
|||
| Type: | Extraction Equipment | Product Type: | OLIVE OIL |
|---|---|---|---|
| Condition: | New | Video Outgoing-inspection: | Provided |
| Machinery Test Report: | Provided | Marketing Type: | Olive Oil Mill |
| Warranty Of Core Components: | 2 Years | Core Components: | PLC, Bearing, Gear |
| Voltage: | 220V/380V/415V/440V | Power: | 60KW |
| Weight: | 6000 | Dimension(L*W*H): | 4600X1250X1400MM |
| Warranty: | 2 Years | Key Selling Points: | Long Service Life |
| Applicable Industries: | Food & Beverage Factory, Farms | Showroom Location: | Italy, Peru, Mexico, Kenya |
| Product Name: | Olive Oil Decanter Centrifuge | Model: | EVOT-5 |
| Capacity: | 5000-6000KG/H | Separation Method: | 3-phase |
| Rotation Speed: | Max.3000rpm | Speed Control: | Frequency Inverter |
| Differential Speed: | 2rpm-30rpm | Main Motor+Vice Motor: | 60KW |
| Power Supply: | 220V/380V/415V/440V | Dimensions&Weight: | 4600X1250X1400MM/6000KGS |
| Port: | QINGDAO,SHANGHAI | ||
Product Description
EVOT Series Decanter Centrifuge
(Special Design for Olive Oil Production)
EVOT series decanter centrifuge is designed specially for olive oil extraction from the ready paste by 2-phase or 3-phase separation. Together with our polishing separator,customer can produce the extra virgin olive oil.
EVOT Two Phase Decanter Centrifuge
EVOT Series 2 Phase decanter centrifuge is designed for olive oil extraction to avoid waste water pollution issues
EVOT Three Phase Decanter Centrifuge
EVOT Series 3 Phase decanter centrifuge is designed for olive oil extraction to get more drier olive pomace
Specification
MODEL | EVOT-2 | EVOT-3 | EVOT-4 | EVOT-5 | EVOT-6 | |||
CAPACITY | 500KG/H | 2000KG/H | 4000KG/H | 6000KG/H | 8000KG/H | |||
SEPARATION | 2-PHASE | 2/3-PHASE | 2/3-PHASE | 2/3-PHASE | 2/3-PHASE | |||
MAX.SPEED | 4500RPM | 3600RPM | 3300RPM | 3000RPM | 2800RPM | |||
MATERIAL | SUS304 | 304/316/2205/2507 (DIN 1.4301/1.4401/1.4462/1.4410) | ||||||
DIMENSION | 2700*800*900MM | 3500*1000*1250MM | 4200*1200*1300MM | 4600*1500*1600MM | 4800*1800*1900MM | |||
