200TPD Olive Oil Mill Tricanter Decanter Centrifuge with Frequency Inverter Speed Control
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | HENAN SOLID |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $140,000.00 - $170,000.00/sets |
| Packaging Details: | All core equipment and spare parts are packed by exported standard wooden cases. |
| Supply Ability: | 30 Set/Sets per Year |
|
Detail Information |
|||
| Applicable Industries: | Food & Beverage Factory | Max Capacity: | 10 T/H |
|---|---|---|---|
| Showroom Location: | Mexico, Kenya | Condition: | New |
| Use: | OLIVE OIL | Type: | Cold & Hot Pressing Machine |
| Automatic Grade: | Automatic | Production Capacity: | 99% |
| Voltage: | 220V/380V/415V/440V | Dimension(L*W*H): | 5700X1500X1500MM |
| Weight: | 11000 KG | Warranty: | 1 Year |
| Key Selling Points: | Long Service Life | Marketing Type: | New Product 2020 |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Warranty Of Core Components: | 1 Year | Core Components: | Bearing |
| Oil Type: | OLIVE OIL | Product Name: | Avocado Oil Decanter Centrifuge |
| Model: | AVOT-6 | Capacity: | 8-10T/h |
| Separation Method: | 2-phase | Rotation Speed: | Max.3600rpm |
| Speed Control: | Frequency Inverter | Differential Speed: | 2rpm-31rpm |
| Main Motor+Vice Motor: | 97KW | Power Supply: | 220V/380V/415V/440V |
| Dimensions&Weight: | 5700X1500X1500MM /11000kgs | Port: | QINGDAO,SHANGHAI |
Product Description
EVOT Series Decanter Centrifuge
(Special Design for Olive Oil Production)
EVOT series decanter centrifuge is designed specially for olive oil extraction from the ready paste by 2-phase or 3-phase separation. Together with our polishing separator,customer can produce the extra virgin olive oil.
EVOT-2 Two Phase Decanter Centrifuge
EVOT-2 decanter centrifuge is designed for olive oil extraction,mainly for 300-500kg/h olive oil extraction line
EVOT-6 Three Phase Decanter Centrifuge
EVOT-4 decanter centrifuge is designed for olive oil extraction,mainly for 8T/H-10T/H olive oil extraction line
Specification
MODEL | EVOT-2 | EVOT-3 | EVOT-4 | EVOT-5 | EVOT-6 | |||
CAPACITY | 500KG/H | 2000KG/H | 4000KG/H | 6000kg/h | 10000kg/h | |||
SEPARATION | 2-PHASE | 2/3-PHASE | 2/3-PHASE | 2/3-PHASE | 2/3-PHASE | |||
SPEED | 4200RPM | 3600RPM | 3300RPM | 2800RPM | 3000RPM | |||
MATERIAL | SUS304 | 304/316/2205/2507 (DIN 1.4301/1.4401/1.4462/1.4410) | ||||||
DIMENSION | 2700*800*900MM | 3500*1000*1250MM | 4200*1200*1300MM | 4600*1500*1600MM | 4800*1800*1900MM | |||
Packing & Delivery
